Products Description
Growatt WIT 10K-XHU Inverter: Meanwhile, power your home, with confidence and clarity. In an era of increased energy reliability, efficiency, and adaptability, the Growatt WIT 10K-XHU Inverter presents itself as a reliable option for homeowners searching for a smarter, more durable energy option. The WIT 10K-XHU is more than just an upgrade to your home performance; it is a thoughtfully designed, engineered system that creates convenience in generating, using, and managing electricity while leading a lifestyle that shows care for sustainability, convenience, and peace of mind. Whether you are developing an energy-efficient home or adding or upgrading to an existing system, the WIT 10K-XHU is designed for you to expand.
Key Features
High Yields
- More powerful with 2 DC/AC ratio
- Maximum current per string up to 20A
- Maximum PV input voltage up to 1000VDC
Scalable & Flexible
- Compatible with flexible AXE HV batteries
- Support DC-coupled and AC-coupled system
Smart & Reliable
- IP66 protection degree
- MODBUS TCP available
- Support AFCI and online monitoring
Product Advantages
Max. string current up to 20A
Max. charging/discharging current of 55A
110% continuous AC overloading capacity
Support UPS function and black start
Integrated with generator input and smart load control
Technical Specifications
| Datasheet | WIT 10K-XHU |
| Input data (PV) | |
| Max. recommended PV power(for module STC) | 20000W |
| Max. input voltage | 1000V |
| Start voltage | 180V |
| Nominal voltage | 620V |
| MPPT voltage range | 150V-850V |
| Max. input current per MPP tracker | 40A |
| Max. short-circuit current per MPP tracker | 50A |
| No. of MPP trackers | 2 |
| No. of PV strings per MPP tracker | 2 |
| Input/Output Ac (Including the Gen Port) | |
| AC input/output nominal power(Grid) | 16000W/8000W |
| Max. AC input/output apparent power(Grid) | 17600VA/8800VA |
| Max. input/output current(Grid) | 26.67A/13.33A |
| Max, input current(GEN/AC couple) | 24.24A/12.12A |
| Nominal AC voltage/range | 220V/380V,230V/400V,240V/415V,-15%~+10% |
| Nominal AC grid frequency/range | 50/60Hz,45~55Hz/55-65 Hz |
| Adjustable power factor | -1...+1 |
| THDi | <3% |
| AC grid connection type | 3P3W+PE/3P4W+PE |
| Battery data (DC) | |
| Battery type | Lithium-ion |
| Battery voltage range | 120-800V |
| Max charging and discharging current | 55A |
| Recommended battery voltage | 512V |
| BMS communication | RS485/CAN |
| Backup power (AC)* | |
| Rated AC output power | 10000W |
| Max, AC apparent power | 2 times of rated power, 10s |
| Rated AC output voltage | 220V/380V,230V/400V,240V/415V |
| Nominal AC output frequency | 50/60Hz |
| Max. output current | 30.30A |
| THDv | 3% (Linear load) |
| Load unbalance | 100% three-phase unbalanced |
| On/off grid transfer time | <10ms |
| Efficiency | |
| Max. efficiency | 98.10% |
| European efficiency | 97.20% |
| MPPT efficiency | 99.90% |
| Protection devices | |
| PV reverse polarity protection | Yes |
| DC switch | Yes |
| DC/AC surge protection | Type ll/Type ll |
| Insulation resistance monitoring | Yes |
| Residual-current monitoring unit | Yes |
| AC short-circuit protection | Yes |
| Ground fault monitoring | Yes |
| Grid monitoring | Yes |
| Strings monitoring | Yes |
| Anti-islanding protection | Yes |
| AFCl function | Opt |
| General | |
| Dimensions (W/H/D) | 465x644x241mm |
| Weight | 45kg |
| Operating temperature range | -30℃... +60℃(> 45°c, derating) |
| Noise | ≤55dB(A) |
| Relative humidity | 0~100% |
| Altitude | 400m |
| Topology | Transformeress |
| Cooling | Smart air cooling |
| IP degree | IP66 |
| Display | OLED/LED+APP |
| Interfaces: RS485/USB | Yes |
| Interfaces: WIFI/LAN | Yes |
| Warranty(5/10 vears) | Yes/Opt |
Designed for the Way You Live
Managing energy doesn't have to be a challenge-it's designed to fit into your everyday life. WIT 10K-XHU was produced with this philosophy, leveraging a friendly and convenient process for you as the end user. Installation will be as minimally disruptive as possible, whether you are using a contractor professionally or a DIY (where permitted). As professionally installed, once operational, it will require little to no maintenance, so you will simply enjoy the service rather than needing to fret about regular maintenance.
It's compact, quiet form factor means it can be installed absolutely anywhere in your home-and blends right in whether installed in a utility closet, garage, or outdoor enclosure. More importantly, it will not make any noise while working, even during high demand draws or use. This design consideration will allow for uninterrupted comfort, while adding value, protecting the environment, and providing a convenient energy management solution.
