Hebei Mutian Solar Energy Technology Development Co., Ltd. is one of the most reliable manufacturers and suppliers of growatt spm 10000tl-hu inverter in China, also supports customized service. Welcome to buy advanced growatt spm 10000tl-hu inverter in stock from our factory.
Products Description-Growatt SPM 10000TL-HU Inverter
Energy should make your life simpler, not more difficult. The SPM 10000TL-HU quietly works behind the scenes and converts sunlight effortlessly into reliable electricity, and in exactly the same way and reliability as grid power, just cleaner and on purpose. Given your lifestyle choices, whether it's working from home, charging devices around the house, cooking meals for family and friends, or enjoying entertainment, this inverter provides all the steady reliable power you need.
Key Features
•High-Efficiency Conversion: Maximizes the energy harvest from your solar panels to boost your savings.
•Remote Monitoring: Easily track performance and savings in real-time via your smart device.
•Quiet and Robust Operation: Designed for reliable, low-noise performance in your home.
•Future-Ready Platform: The intelligent core for a modern home energy system.
•User-Centric Design: Simplifies the experience of owning and understanding your solar power.
•Global Expertise: Backed by the quality and support of an industry leader.
Technical Specifications
| Datasheet | Growatt SPM 10000TL-HU Inverter |
| Input data (DC) | 20000W |
| Max. input power for single MPPT | 8000W+8000W+15000W |
| Max. DC voltage | 600V |
| Start voltage | 120V |
| MPP voltage range | 150-550V/370V |
| No. of MPP trackers | 3 |
| No. of PV strings per MPP tracker | 2 |
| Max. input current per MPP tracker | 16A+16A+32A |
| Max. short-circuit current per MPP tracker | 22A+22A+40A |
| AC input data (AC) | |
| Nominal AC input power | 9999W |
| Nominal input voltage | 230V |
| Nominal input current | 43.4A |
| Max. grid passthrough power | 15000W |
| Max. generator input power | 9999W |
| Output data (AC) | |
| AC nominal power | 9999W |
| Max. AC apparent power | 9999VA |
| Nominal AC voltage (range*) | 230V |
| AC grid frequency (range*) | 50Hz |
| Max. output current | 50A |
| Adjustable power factor | 0.8leading…0.8lagging |
| THDi | <3% |
| AC grid connection type | Single phase |
| Battery data (DC) | |
| AC nominal output power | 9999W |
| Nominal AC output voltage | 230V single phase |
| Nominal AC output frequency | 50Hz |
| Switch time | <10ms |
| Overload capability | 150% Full Load@5S |
| Efficiency | |
| Peak. efficiency | 97.50% |
| Europe efficiency | 96.50% |
| MPPT efficiency | ≥99.5% |
| Protection devices | |
| PV switch | Yes |
| AC over current protection | Yes |
| AC over voltage protection | Yes |
| Ground fault monitoring | Yes |
| Grid monitoring | Yes |
| Anti-islanding protection | Yes |
| Residual-current monitoring unit | Yes |
| Insulation resistance monitoring | Yes |
| AFCI protection | Yes |
| Surge protection | Yes |
| General data | |
| Max stackable number | 6 |
| Dimensions (W / H / D) | 440/883/254mm |
| Weight | 48.84kg |
| Operating temperature range | –25°C ... +60°Cwith derating above 45°C |
| Noise emission (typical) | ≤ 60 dB(A) |
| Self-Consumption | < 60 W |
| Topology | Transformerless |
| Cooling | Smart cooling |
| Protection degree | IP65 |
| Relative humidity | 0~100% |
| Altitude | 2000m |
| Display | LCD touch screen |
| Interfaces: RS485/CAN/USB | Yes |
| Communication | WIFI/LAN |
| Warranty | 10 years |
| CE, G99, G100, AS 477.2:2020, AS 609473, CSIP-AUS | |
about us
The Reasons Why Families Select Us:
✓ Prevent Power Outages
During extended blackouts, continue vital functions including running medical equipment, keeping connected, and refrigerating food.
✓ Reduce the Cost of Electricity
No longer dependent on costly diesel generators or grid electricity.
With more batteries, the Future-Proof Energy Independence System can expand.
✓ No emissions
Clean, quiet energy reduces engine emissions and the carbon footprint.
✓ Low Upkeep
Long-lasting LFP batteries don't need complicated maintenance and survive for more than ten years.
Real Solution: A four-person home using 25kWh is experiencing blackouts for eight hours every day.
If you want to take part in the off-grid solar panel systems market or need more details, please feel free to contact us.
From Order to Operation – Simple, Fast, Supported
Free Consultation – Call or fill out our 2‑minute form. We'll review your roof space, energy usage, and goals.
Custom Design – Within 48 hours, you receive a layout drawing, savings projection, and firm price.
Permitting & Logistics – We handle permit application support (or you can DIY with our guides). The complete system ships within 7 days.
Installation – Use our recommended local installers (or your own electrician – we provide detailed wiring diagrams and remote guidance).
Activation & Smile – Flip the switch. Watch your meter run backward. Enjoy peace of mind.
For DIY‑friendly customers, the system ships pre‑assembled in modular sections. Most homeowners with basic tools complete the install in a weekend.
